Specifications Product Specifications
29 - 14 V Series Operating Instructions
29.1.14 BIS Module Safety Designations:
29.1.15 Visual and Auditory Alarm Disclosure
• The V 12/V 21 I/O Processor generates a high priority LED alarm.
• The high priority LED alarm has a flashing frequency of 2 Hz.
• The high priority LED alarm has a duty cycle of 50%.
• The V 12/V 21 I/O Processor generates a medium priority LED alarm.
• The medium priority LED alarm has a flashing frequency of 0.5 Hz.
• The medium priority LED alarm has a duty cycle of 50%.
• The V 12/V 21 I/O Processor generates a low priority LED alarm.
• The low priority LED alarm is constantly on.
• The low priority LED alarm has a duty cycle of 100%.
TABLE 29-14
Type of protection against electric shock: Class II
Degree of protection against electric shock: BIS- Type BF,
Supply Connection: +12VDC, +5VDC from Module Bay
Mode of Operation: Continuous
Protection Against Hazards of Explosion: Not protected (Ordinary)
Protection Against Ingress of Liquids: Drip-proof (IPX1)
Degree of electrical connection between
equipment and patient:
Equipment designed for direct electrical connection to the
patient
Degree of Mobility: Portable
Maximum Size: 0.988“H x 6.2”W x 5.5”D
Maximum Weight: 0.75 lbs.
Operating Temperature: +5°C to +40°C
Operating Humidity: 15% to 95%, non-condensing
Operating Altitude: 1060hPa to 700hPa
Storage Temperature: -20°C to +60°C
Storage Humidity: 10% to 95%, non-condensing
Storage Altitude: 1060hPa to 570hPa
Controls/Indicators: 1-Button, Check Sensor Button
1- LED, Powered and Communicating
Interfaces: 1- BIS
1- Module Bay (Mx)
