29 - 22 V Series Operating Instructions
• Arrhythmia analysis is disabled in neonatal mode.
• Non-lethal arrhythmia alarms can be disabled.
• All arrhythmia alarms can be disabled unless locked by a password protected setting.
The ECG module has ability to make following calls as applicable per ECG source:
• Asystole
• Bigeminy
•QTc
•Couplet
• Irregular Heart Rate
•Multiform PVC
•Pause
• Pauses/Minute
•R-On-T PVCs
•PVCs/Minute
•Run
•Trigeminy
• Ventricular Fibrillation
• Ventricular Rhythm
• Ventricular Tachycardia
B. 12 Lead ECG
• The 12 Lead ECG functions in conjunction with the VPS.
1. Lead Definition
2. 12 Lead ECG Cable Detection
The ECG System has a manual selection for 12 Lead cables when Mindray cables are used.
3. Defibrillator Overload protection
The ECG function is in accordance with the applicable requirements of IEC 60601-2-27 and IEC 60601-
2-25.
4. ECG Signal Range
• ± 5mV (peak-to-peak value); the output accuracy of signals complies with 50.102.1 of IEC60601-2-
27:2011.
5. Calibration Signal
TABLE 29-21
ECG TYPE ACQUIRED LEADS DISPLAYABLE LEADS
12 Lead ECG I, II, V1, V2, V3, V4, V5, V6 I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
