ECG Performance Product Specifications
29 - 24 V Series Operating Instructions
20. Impulse response
Impulse response is as per (IEC60601-2-27:2011).
21. Notch Filter Selection
ECG System is equipped with 50 Hz or 60 Hz notch filter with option to turn off.
22. CMMR
CMMR is as per (IEC60601-2-27:2011). Notch filter is turned off.
23. Pacer Enhancement
Pacer signals within the range ±2mV and ± 700mV (RTI) amplitude with a maximum rise time of
100µsec and with duration in the 0.1ms to 2.0ms range are enhanced on the display when the Pacer
Enhancement Mode is turned ON.
24. ESIS Filtering
The 12 Lead ECG does not provide ESU protection or suppression.
25. Leads-off Detection Current
The leads-off detection current to the patient is lesser than 0.1 A.
26. ESU Noise Detection
The 12 Lead ECG does not provide ESU protection or suppression.
27. ESU Noise Suppression
The current of an ESU noise suppression is lesser than 1 A.
28. ECG Heart Rate Meter
The ECG heart rate meter function is derived from the ECG waveform.
Range:
29. Resolution
Resolution is 1 BPM.
30. Accuracy
Accuracy is ± 3 BPM or ± 3% from 30 to 250 BPM, ± 5% in the 251 to 300 BPM range.
31. Out of Range
For values outside the specified measurement range, the heart rate meter indicates invalid data as
(- -).
32. Trigger Indication
12 Lead ECG 0.5 to 40 Hz 0.05 to 150 Hz 0.05 to 40 Hz
TABLE 29-23
ECG Source: Adult Range (BPM) Pediatric Range:
(BPM)
Neonatal Range:
(BPM)
12 Lead ECG 20 to 300 20 to 300 20 to 350
TABLE 29-22
ECG Type Bandwidth (-3db)
