4.7.1.1.3 Range mode: Multi-interval scale
In this menu item (under Parameters), a multi-interval scale (of Class III or single-range
scale of Class I and II with variable scale interval) of the Internal weighing point weighing
electronics is congured
The multi-interval scale is a scale with a weighing range that is divided into intervals. Each
interval range has a dierent scale interval, where the weighing range is automatically
switched depending on the load on the scale and also when the load is placed on/
removed from the scale.
When [Range mode] = [Multi-interval], the scale has up to three ranges with dierent
resolution.
The weight display header includes the current interval range (R1, R2, or R3), Max, Min,
and d (or e with devices used in legal metrology) (Example: multi-interval scale in
range R2):
WP-A R2 Max 2000kg d=
Min 40kg e= 2kg
The parameters [Range limit 1] and [Range limit 2] are the interval ranges. As soon as the
gross weight exceeds range 1, the next highest range with the next highest scale interval
becomes valid (1, 2, 5, 10, 20, 50).
Note:
During calibration, the multi-interval function is always switched o.
Example
Range mode: Multi-interval
Interval range 1: 0…1500 g (when calibrating set scale interval: 0.1 g)
Interval range 2: 1500…2900 g (next highest scale interval: 0.2 g)
Accessible via MENU - [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [Parameters] - [Range mode] - [Multi-interval scale] .
2. Select and conrm [Multi-range].
3. Congure switch point from range 1 to 2: enter 1000.0 g for [Range limit 1]
4. Congure switch point from range 2 to 3: enter 2000.0 g for [Range limit 2]
5. Press the [Save] soft key to save the settings.
