WP-C R1 Max 29.9kg d= 0.0005kg
01000
–
kg
xBPI scale setup @admin
Dead load
Set
Delete
SPAN
Adjust with user weight
Adjust with automatic weight
WP-C R1 Max 29.9kg d= 0.0005kg
50000
+
kg
xBPI scale setup @admin
Dead load
Set
Delete
SPAN
Adjust with user weight
Adjust with automatic weight
Enter user weight.
2.5165 kg
Unit
WP-C R1 Max 29.9kg d= 0.0005kg
56152
–
xBPI scale setup @admin
Calibration check
input
input
Load to small
-2.5165 kg
-0.00015 kg
Accept Reset error Cancel
1. Select and conrm [Adjust with user weight].
An input window opens. The previously stored user weight is displayed.
2. If necessary, change the weight value using the keyboard and conrm.
The calibration process is performed without a weight and the calibration check
indicates the status.
3. Place the weight on the scale.
The deviation is shown. Weight + deviation with 10-fold resolution in the last line.
