WP-C R1 Max 29.9kg d= 0.0005kg
00000
kg
xBPI scale setup @admin
Dead load
Set
Delete
SPAN
Adjust with user weight
Adjust with automatic weight
WP-C R1 Max 29.9kg d= 0.0005kg
00000
kg
xBPI scale setup @admin
NET
input
0.0000 kg
-0.00005 kg
Accept Reset error Cancel
4.7.5.3.3 Adjust with user weight
In this menu item, the xBPI scale weighing electronics are calibrated with a user-dened
weight.
Requirements:
- The xBPI protocol has been selected, see Chapter 4.7.5.1.
- The [xBPI scale] weighing point has been selected, see Chapter 4.7.5.
- The scale has been set up, see Chapter 4.7.5.5.
- [Manual] has been set in the menu [Operating] - [System setup] - [Weighing points] -
[Weighing point x] - [Setup] - [Conguration] - [Weighing parameters] - [Conrm
calibration] , see Chapter 4.7.5.5.1.1.
- The communication between the device and xBPI scale is active.
- the xBPI scale parameters have been read, see Chapter 4.7.5.3.
Accessible via MENU - [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [xBPI scale] - [Calib] - [Adjust with user weight] .
1. Remove the weight from the scale.
2. Select and conrm [Delete].
The stored dead load is deleted. The current dead load is shown on the weight
display.
3. Press the EXIT key to return to the xBPI setup menu.
