Minebea Intec PR5900 - Page 184

WP-D Max 200t d= 0.02t
0.000 t
Calibration @admin
Local gravity
Max
Scale interval
Dead load
Calibration weight
Corner correction
9.81379 m/s²
200.000 t
0.020 t
7.505 t
11.000 t
correction ok
10000 d
1 d
Platform 1 by load by value Save
4.7.7.3.5 Assign load cell name
In this menu item (under Calib), each load cell of the digital weighbridge load cell
Pendeo
®
Truck can be given a name.
Accessible via MENU - [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [Calib] - [Assign load cell name] .
WP-D Max 200t d= 0.02t
0.000 t
Weighing points @admin
Setup Pendeo
Quick install with search load cells and set dead load
Search for connected load cells
View and assign load cells
Calibrate the scale
Assign load cell name
Service function for load cells
2. Select and conrm [Dead load].
3. Conrm the dead load (∑ corner load).
4. Check the corner load; see Chapter 4.7.7.3.7.
5. Perform a corner correction if necessary; see Chapter 4.7.7.3.7.
6. Press the [Save] soft key to save the current dead load.
1. Select and conrm [Assign load cell name].
An input window opens.
