0.000 t
Load cell name @admin
LC 1
LC 2
LC 3
LC 4
101
103
104
102
PR 6204-RU
Default Save
ABC..
4.7.7.3.6 Service function for load cells
In this menu item (under Calib), faulty load cells of the digital weighbridge load cell
Pendeo
®
Truck can be deactivated and replacement load cells activated.
Accessible via MENU – [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [Calib] - [Service function for load cells].
WP-D Max 192t d= 0.02t
0.000 t
Weighing points @admin
Setup Pendeo
Quick install with search load cells and set dead load
Search for connected load cells
View and assign load cells
Calibrate the scale
Assign load cell name
Service function for load cells
0.000 t
Service @admin
LC 1
LC 2
LC 3
LC 4
101
103
104
102
1.350 t
1.506 t
2.197 t
2.457 t
1.491 t
1.650 t
2.056 t
2.315 t
Accept
Item number, serial number, dead load, and current load of connected load cells are
displayed.
2. Select the load cells in succession, enter the name using the keyboard and conrm.
3. Press the [Save] soft key to save the entry.
1. Select and conrm [Service function for load cells].
The service window opens.
4 System setup Process Controller Maxxis 5 PR 5900
EN-183 Minebea Intec
