Minebea Intec PR5900 - Page 183

WP-D Max 200t d= 0.02t
7.520+ t
Calibration @admin
Local gravity
Max
Scale interval
Dead load
Calibration weight
Corner correction
9.81379 m/s²
200.000 t
0.020 t
0.000 t
10000 d
1 d
New Modify
The data from the last calibration is displayed.
Note:
The menu item [Modify] is only used for minor changes (e.g. changing the dead
load/preload). Otherwise, the menu item [New] should be selected.
WP-D Max 200t d= 0.02t
7.520+ t
Calibration @admin
1
2
3
Local gravity
Max
Scale interval
Dead load
Calibration weight
Corner correction
9.81379 m/s²
200.000 t
0.020 t
10000 d
1 d
Platform 1 Save
For description and settings of the parameters, refer to Chapter 4.7.7.3.4.1.
4.7.7.3.4.3 Dead load (correction)
In this menu item, the dead load is modied for the digital weighbridge load cell
Pendeo
®
Truck.
If the platform weight changes by an amount that is higher than the zero range, e.g., due
to dead load reduction, dead load increase, or mechanical changes, the functions for
automatic zero tracking and manual zero setting no longer work.
If the entire zeroset range is already utilized, you can still correct the dead load without
aecting other calibration data/parameters.
Accessible via MENU - [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [Calib] - [Calibrate the scale] - [Modify] - [Dead load] .
1. Press the [Modify] soft key.
2. Select the individual parameters and conrm.
3. Press the [Save] soft key to save the calibration.
1. The scale must be empty (deck installed on a vehicle scale, no load).
