Test mode 1
Display
System
Inputs
Outputs
Application
Active PLC:
- The physical inputs of the system are directed to the PLC (application).
- The physical outputs of the system are set by the PLC (application).
- The physical inputs and outputs are displayed (display).
Test mode 2
Display
System
Inputs
Outputs
Application
Active PLC:
- The entered input values are sent to the PLC (application).
- The PLC output is displayed (display).
6 System maintenance Process Controller Maxxis 5 PR 5900
EN-337 Minebea Intec
