6.11.3.3 Adapting the analog output: PR 5900/07
Example test (under I/O cards test) of an analog input/output card.
The output current can be adjusted in small ranges. This is required if small deviations
from the nominal value occur in a connected PLC.
Accessible via MENU - [Operating] - [System maintenance]- [Test hardware]- [I/O cards
test] in this case, card: PR 5900/07.
Test I/O-Cards
Built-in RS-232/RS-485
Option-1
Option-2
Built-in Digital I/O
Option-FB
WP A
WP B
PR5900/07 Analog I/O
PR5900/07 Analog E/A
PR5900/W1 weighing electronics
-empty-
-Empty-
Test I/O-Cards
Option-1
in use by PLC task
Test mode
Analog output, current
Analog input 1, current
Analog input 2, voltage
PR5900/07 Analog I/O
2
Monitoring
9.291 mA
5.072 mA
0.000 V
Monitor Intern Extern
Test mode 1 [Monitoring] is active.
4. Press EXIT to return to the previous window.
1. Select and conrm the desired card (here: PR 5900/07).
An information window is displayed.
2. Press the [Extern] soft key.
An information window is displayed.
