Test I/O-Cards
1
2
3
Option-1
in use by PLC task
Test mode
Analog output, current
Analog input 1, current
Analog input 2, voltage
PR5900/07 Analog I/O
2
External test
9.289 mA
5.081 mA
0.440 V
Monitor Intern Extern Adjust Reset
Test mode 3 [External test] is active.
Adjust analog output
1
2
3
Output
Measured
4.000 mA
3.925 mA
Adjust analog output
Output
Measured
20.000 mA
19.856 mA
3. Press the [Adjust] soft key.
4. Enter and conrm e.g.the value for 4 mA measured by the connected PLC under
[Measured].
An information window is displayed for the second value (20 mA).
5. Enter and conrm e.g.the value for 20 mA measured by the connected PLC under
[Measured].
A prompt window appears.
