Adjust analog output
1
2
3
Output
Measured
20.000 mA
19.856 mA
?
Save settings
Yes No
Or
Test I/O-Cards
1
2
3
Option-1
in use by PLC task
Test mode
Analog output, current
Analog input 1, current
Analog input 2, voltage
PR5900/07 Analog I/O
2
External test
9.289 mA
5.081 mA
0.440 V
Monitor Intern Extern Adjust Reset
?
Reset to default?
Yes No
6.11.3.4 Example: PR 5900/12
Example test (under I/O cards test) of a digital input/output card.
Accessible via MENU - [Operating] - [System maintenance] - [Test hardware] - [I/O cards
test] in this case, card: PR 5900/12.
Test I/O-Cards @admin
Built-in RS-232/RS-485
Option-1
Option-2
Built-in Digital I/O
Option-FB
WP A
WP B
PR5900/04 RS-485/RS-485
PR5900/12 Digital I/O
PR5900/W1 weighing electronics
PR5900/W1 weighing electronics
-empty-
6. Press the [Yes] soft key to save the settings.
7. Press the [Reset] soft key to reset to the factory settings (4 mA and 20 mA).
A prompt window appears.
8. Press the [Yes] soft key to reset to the factory settings.
9. Press the EXIT key to return to the card test menu.
