Minebea Intec X3 Process Indicator PR 5410 User Manual

Data type Description Value range
BYTE bit-sequence 8 …
WORD bit-sequence 16 …
DWORD bit-sequence 32 …
LWORD bit-sequence 64 …
13.3 Addressing
The SPM table can be addressed via dierent counts. Bit addressing is used to count the
individual bits (MX). Byte addressing is used to count individual bytes (MB), whereby,
e.g.bits MX0MX7 are identical to byte MB0.
Code Data type Address example
%ML LWORD L21
%MD DINT
D4243
%MW WORD
W8487
%MB BYTE
B168175
%MX BOOL (bit)
X13441407
13.4 System data
SPM address Data type R/W Function
X0–X2 BOOL R Digital input 1–3
X8–10 BOOL R Digital output 1–3
X16–18 BOOL R Standard only: Output limit 1–3
B4
X32
X33
X34
X35
X36
X37
X38
X39
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
R
R
R
R
R
R
R
R
R
Indicator status
ADC error
> Max (FSD)
> Max + permitted range (OVL)
< zero
Zero ±¼ d
Within the zeroset range (ZSR)
The weight is stable
Weight < zero or > Max (FSD)
B5
X40
X41
X42
X43
X44
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
R
R
R
R
R
R
ADC status
Measuring signal negative (error 7)
Measuring signal >36 mV (error 3)
Internal arithmetic error; CAL data are perhaps faulty (error 1)
No or too low sense voltage (error 6)
No communication with xBPI scale (error 9)
13 SPM X3 Process Indicator PR 5410
EN-315 Minebea Intec
