Minebea Intec X3 Process Indicator PR 5410 User Manual

PR 5410 switch settings PR 5410 conguration
ON: S1, S2, S3, S4, S5
OFF: …
- [Serial ports parameter]- [xBPI-Port]- [Slot 1/2 RS485]
Note:
For further information, see the installation manuals relating to the load cells and junction boxes.
4.6.4 Analog inputs and outputs
This interface card has the type designation PR 5510/07.
The plug-in card has one active analog output and four analog inputs. The analog inputs
are not supported by the standard device.
Only one PR 5510/07 card can be plugged into "Slot 1" or "Slot 2."
X3 Process Indicator PR 5410 4 Device installation
Minebea Intec EN-72
