4 Device installation
4.1 General information
Before starting work, please read Chapter 2 and follow all instructions.
WARNING
Warning of a hazard area and/or risk of personal injury
All cable connections must be protected against damage.
Note:
- Measurement cables should be kept away from power equipment.
- Signal cables and measurement cables should be installed separately from electric
power lines.
- It is recommended that measurement cables are laid in separate cable conduits.
- Power cables should be crossed at right angles.
Further procedures:
- Check the consignment: make sure that all components are present.
- Safety check: inspect all components for damage.
- Make sure that the on-site installation is correct and complete including cables, e.g.,
power cable fuse protection, load cells, junction box, data cables, console/cabinet,
etc.
- If necessary, install the plug-in cards (device must be disconnected from all voltage
sources).
- Follow all device installation instructions related to application, safety, ventilation,
sealing, and environmental inuences.
- Connect the cable from the junction box or platform/load cell.
- If applicable: connect other data cables, network cables, etc.
- Connect to supply voltage.
- Check the installation.
4.2 Mechanical preparation
4.2.1 Mechanical preparation
Have all required parts, technical documents, and tools at hand for control cabinet
installation.
Other procedures:
- Make the control panel cut-out for the device in the control cabinet door, for
example; see Chapter 3.3.3.
- Install the device.
- Secure the cable at the place of installation, e.g., using cable ties.
4 Device installation X3 Process Indicator PR 5410
EN-31 Minebea Intec
