Register 85 ResetPwf Reset the PowerFail bit (Register 1; the bit was
set after power on).
Register 86 SetFixTare Taring with weight in numerical address D 31
"Fixtare."
Register 87 GetFixTare The current gross weight is copied into numeri-
cal address D31.
Register 89 ResetError The CmdError error bit is reset.
Register 90 GetAlibi Export selected data record from alibi memory.
Register 91 GetDate Read current date and time.
Register 92 SetDate Store (set) current date and time.
12.2.6.13 Registers 112…124: Transition-controlled action bits (Write)
For setting bits, see Chapter 12.2.4.3.
As soon as the bit was set, it is reset internally and the operation is handled; this is
transition-controlled (for writing once).
The bit is set as Write_Value_Select with the specied number (see Chapter 12.2.4.3).
Register 112 SetZero
Register 113 SetTare
Register 114 ResetTare
Register 115 SetTest
Register 116 ResetTest
Register 117 ResetPwf
Register 118 SetFixTare
Register 119 GetFixTare
Register 121 ResetError
Register 122 GetAlibi
Register 123 GetDate
Register 124 SetDate
Note:
To prevent excessively frequent writing in the EAROM memory, the write interval should
not be less than 15 seconds.
12.3 Filling protocol (64-Byte) for the "EasyFill" application
The "EasyFill" application uses a 64-byte interface.
The 8-byte scale protocol for the "Standard" application is not available.
12.3.1 Write window (input area)
Data are transferred from the master (PLC) to the slave (PR 5410) in this window.
12 Fieldbus interface X3 Process Indicator PR 5410
EN-305 Minebea Intec
