16 Error messages
16.1 Error messages measuring circuit
The internal weighing electronics can generate error messages, which are shown on the
weight display.
Display VNC text Error and possible cause Remote dis-
play
Error 1 Arith. error Internal arithmetic overow:
- Faulty calibration values.
Error 1
Error 2 Overload The measuring signal is higher than Max + (x d):
- Wrong setting.
- Too much weight on the scale.
Error 2
Error 3 Ext. meas. device error Measuring input open:
- The measuring signal is higher than the per-
missible range of 36 mV.
- Measuring cable is interrupted (cable break
detection).
- Other hardware defect.
Error 3
Error 4 Value exceeds display The weight value is not displayed:
- Too many digits have been set.
Error 4
Error 6 No sense voltage No sense voltage:
- Load cells not connected.
- Sense line or supply line is interrupted.
- Wrong polarity or sense voltage is low.
Error 6
Error 7 Negative input Negative measuring signal:
- Wrong polarity of load cell signal.
- Wrong polarity of load cell supply voltage.
Error 7
Error 9 No values from scale Internal weighing point:
The measuring signal is higher than the permis-
sible range of 36 mV. Cannot read weight values
from ADC (analog-digital converter).
- Error in weighing electronics board.
- Defective load cell.
- Cable break.
Error 9
Negative signal Negative weight Display area
Max-¼ d +¼ d0
Overload none EOC
X3 Process Indicator PR 5410 16 Error messages
Minebea Intec EN-324
