9.2.3 Conguration printout
With the [Conguration Printout] menu item the conguration of the device of the device
can be displayed, saved and printed out.
Note:
The conguration printout can be activated via and (clicked one after the
other); see Chapter 7.17.4.
9.2.4 Log les
With the [Logles] menu item the logles of the device can be displayed, saved and
printed out.
A status window opens in which the weight of the weighing point is displayed
with unit and the status symbols.
2. Click on the symbol in the Internet browser to return to the WEB menu.
3. Click on the [Indicator Pop-up Window] menu item in the WEB menu.
A separate status window opens in which the weight of the weighing point is
displayed with unit and the status symbols.
4. Click on the symbol to return to the WEB menu.
1. Click the [Conguration Printout] menu item in the WEB menu.
The conguration of the device is shown on the display.
2. Click on [File]- [Save as].
3. Create and open the required directory e.g.on the notebook.
4. Click on [Save] to save the text le in the relevant directory.
5. Click on [Print]- [File].
6. Select the connected printer and click [Print].
7. Click on the symbol in the Internet browser to return to the WEB menu.
1. Click the [Logles] menu item in the WEB menu.
9 Extended functions X3 Process Indicator PR 5410
EN-273 Minebea Intec
