It is applied to pin 25 (DATA_IN) of the 26-pin connector and is eective only with
switches S101-1 = OFF and S101-2 = ON.
The switch settings can be found in the table in Chapter 4.6.7.
4.6.7 Switch settings
Switch S101
Input External supply S101
for
-1 -2 -3 -4 -5
DATA_IN 5 V active-
high
PIN 25 OFF ON ON ON ON or
OFF
DATA_IN 5 V active-
low
PIN 25 OFF ON ON OFF ON or
OFF
DATA_IN 24 V active-
high
PIN 25 OFF ON OFF ON ON or
OFF
DATA_IN 24 V active-
low
PIN 25 OFF ON OFF OFF ON or
OFF
activate internal free-wheel diode ON
do not activate internal free-wheel diode OFF
Switch S102
Input (PIN 25) Function for the
output data
S102
for
-1 -2 -3 -4 -5
DATA_IN follow hold
PIN 224
OFF OFF ON ON or
OFF
ON or
OFF
DATA_IN tristate follow
PIN 224
ON ON OFF ON or
OFF
ON or
OFF
DATA_IN tristate hold
PIN 224
ON ON ON ON or
OFF
ON or
OFF
Input level
Input (PIN 25) External supply Voltage Current
DATA_IN 5 V active-high >3.1 V >0.5 mA
DATA_IN 5 V active-low <1.5 V <0.3 mA
DATA_IN 24 V active-high >16 V >1.0 mA
DATA_IN 24 V active-low <10 V <0.5 mA
4.6.8 Output modes
In all modes, the data is output during each internal PLC cycle.
