— Filling
— Material ID Material identication
Selection: ID 110
— Material name Material name
Input: max. 18 alphanumeric characters
— Set point Set point
Input: weight; adopt unit from the calibration.
— Preset Preset point for switching from coarse ow to
ne ow. Input: weight; adopt unit from the
calibration.
— Overshoot (OVS) Material overshoot
Input: Weight; adopt unit from the calibration.
— +/- tolerance Tolerance above/below set point
Input: tolerance values; adopt unit from the
calibration.
— Calming time Calming time
Input: in ms
— Start Start lling.
— Stop Stop lling.
— Restart Restart lling.
— Abort Abort lling.
6 "EasyFill" application
6.1 Functions
6.1.1 General information
The "EasyFill" application is used for single-component lling.
The application allows for quick and reliable lling and emptying of containers.
The lling process can be started, stopped, canceled, and restarted via the front-panel
keys, VNC user interface, digital inputs, OPC/Modbus, and eldbus (except CC-Link).
6.1.2 Display functions
- Display of gross, net or tare weight
- Tare/reset tare
- Set gross to zero
- Print weight
- Display of weight values or remote display
- Functions via digital inputs and outputs
- Information interchange via serial I/O, eldbus and network
6.1.3 Filling mode
The "EasyFill" application supports the following lling modes:
- Net lling "B1"
- Net discharge "B4"
6.2 Application menu [Start]
