Minebea Intec X3 Process Indicator PR 5410 User Manual

— Conguration
— Conguration mode Congure the mode
— Dosing mode Filling mode
Selection: Net lling (B1), Net Discharge (B4)
— Interaction mode Interaction mode
Selection: Remote proc. control, VNC, Front
keys
— Print Print conguration.
— Conguration digital I/Os
— Conguration digital
inputs
Congure digital inputs
— 13: SPM address
%MX
Input: SPM address, see Chapter 13.4
— Print Print conguration.
— Conguration digital
outputs
Congure digital outputs
— 13: SPM address
%MX
Input: SPM address, see Chapter 13.4
— Print Print conguration.
— Conguration material
— Material ID Material identication
Selection: ID 110
— Material name Material name
Input: max. 18 alphanumeric characters
— Set point Set point
Input: weight; adopt unit from the calibration.
— Preset Preset point for switching from coarse ow to
ne ow. Input: weight; adopt unit from the
calibration.
— Overshoot (OVS) Material overshoot
Input: weight; adopt unit from the calibration.
— +/- tolerance Tolerance above/below set point
Input: tolerance values; adopt unit from the
calibration.
— Calming time Calming time
Input: in ms
— Default Reset values to 0.
— Print all Print all ID entries.
— Print Print selected ID entry.
— Conguration printing
— Number printouts Number of printouts
Input: 110
— Sequence number Sequence number, see Chapter 8.4.4.
— Use NLE Use NLE
Check the ☑ box to activate printing with
NiceLabelExpress.
— Line 16 Line 16
Selection: see Chapter 8.4.4
— Print Print conguration.
X3 Process Indicator PR 5410 6 "EasyFill" application
Minebea Intec EN-118
