Menu item Selection Description
[0 mA] Set output to 0 mA.
[4 mA] Set output to 4 mA.
[20 mA] Set output to 20 mA.
[Output on error]
[hold] The last output value is held.
[0 mA] Set output to 0 mA.
[4 mA] Set output to 4 mA.
[20 mA] Set output to 20 mA.
[Output if < 0]
[linear] The output drops below 4 mA down to the limit (at
420 mA).
[0 mA] Set output to 0 mA.
[4 mA] Set output to 4 mA.
[20 mA] Set output to 20 mA.
[Output if > Max]
[linear] Output increases above 20 mA until the limit is re-
ached.
[Weight at 0/4 mA] Weight value for 0/4 mA output.
[Weight at 20 mA] Weight value for 20 mA output.
Quit the menu and save parameters by pressing .
Note:
Adapting the analog output, see Chapter 9.1.4.1.
7.18 System information
This menu displays system information.
You can also check inputs and outputs, see Chapter 9.1.4.2.
Note:
also has other functions; see Chapters 7.14.2.2 and 7.14.10.
Press to access the menu.
7 Commissioning X3 Process Indicator PR 5410
EN-239 Minebea Intec
