Legend
No. Description
1 The program searches within the current network ID, e.g. 169.254. and 172.24.,
on all available network adapters in the PC (several possible/recommended,
e.g. LAN global/LAN local)
Result:
List of all connected devices with status: search??? – online - byebye – lost???
2 Click the button to open the "standard" Internet Browser, e.g. Microsoft Inter-
net Explorer, directly with the marked IP‑address.
3 Click the button to localize the associated device.
Short-term visual feedback from the device:
Regular running light in LED 1, 2, 3.
4 Click the button to re-start the network search run.
Waiting 2…3 minutes is essential!
5 Acoustic signal for each device that was detected as "online."
Note:
If the browser window remains empty after the minimum wait time, or if the expected
device is not listed, the network ID of the local notebook/PC must be checked and
changed, if necessary.
Only certain Minebea Intec devices are supported by the "indicator browser"!
7.10 Resetting the network address
This means
- "DHCP" is activated.
- "Hostname" is initialized to, e.g. PR 5410-6B6A5E (type MAC-ID).
Example of MAC ID: 00-90-6C-6B-6A-5E
X3 Process Indicator PR 5410 7 Commissioning
Minebea Intec EN-146
