Minebea Intec X3 Process Indicator PR 5410 User Manual

— CD* Calibration data
— 000 CALIb nEW new calibration, VIEW display data, Mod
modify calibration
— 001 MAX.FSd Decimal point position, Max (scale range) and
weight unit
— 002 StEP Scale interval
— 003 dEAdLo Set dead load with weight (LoAd) or mV/V
(MVoLt)
— 004 SPAn Calibrate range with weight (LoAd) or mV/V
(MVoLt)
— 005 0-rnG Display the used zero-setting range
— 006 uVolt.d Display µV/d
— 007 WEIGHt Display current gross weight; 10-fold resolution
is possible using key.
— CP* Calibration parameter
— 010 MEAtIM Measurement time
— 011 FILtEr Digital lter
— 012 FCut Filter frequency
— 013 tStMod Test mode
— 014 WAM W&M, legal-for-trade
— 015 StStIM Standstill time
7.3 Switching o the device
The device is switched o/disconnected from power supply by pulling the plug.
7.4 Warm-up time
The device requires a warm-up time of 30 minutes before calibration.
7.5 Conguring and calibrating using the front-panel keys
The device can be congured directly using the front-panel keys, with the exception of
the connected xBPI weighing point.
Note:
If an xBPI weighing point is selected, "Err86" appears on the display and it can only be
calibrated via VNC.
7.5.1 Parameter table (SEtuP)
11. Press "OK."
17.35 (SS.MM) appears on the display.
12. Use / and / to make changes accordingly.
13. Press "OK."
dt 086 appears on the display.
14. Press "Exit" to exit the menu.
7 Commissioning X3 Process Indicator PR 5410
EN-123 Minebea Intec
