— 016 StSrnG Standstill range
— 017 TArtIM Timeout for taring/zero-setting
— 018 ZESrnG Zeroset range
— 019 ZEtrnG Zerotrack range
— 020 ZEtStP Zerotrack interval
— 021 ZEttIM Zerotrack time
— 022 oVrLd Overload
— 023 MIn Min.
— 024 MuLrnG Multi-range mode
— 025 rAnG 1 Range 1
— 026 rAnG 2 Range 2
— LI Limits (settings via VNC), for Standard
application only
— 030 LIM.1on, LIM.1oF Limit 1 "On", limit 1 "O"
— 031 LIM.2on, LIM.2oF Limit 2 "On", limit 2 "O"
— 032 LIM.3on, LIM.3oF Limit 3 "On", limit 3 "O"
— LA Limits, action/condition (settings via VNC), for
Standard application only
— 033 LIM.1on Action/condition
— 034 LIM.1oF Action/condition
— 035 LIM.2on Action/condition
— 036 LIM.2oF Action/condition
— 037 LIM.3on Action/condition
— 038 LIM.3oF Action/condition
— do Digital outputs (settings via VNC), for Standard
application only
— 040 bCd.out BCD mode: GroSS; NEtIt = net if tared,
otherwise gross; SELECt; trnSP
— 041 outP. 1 Output 1
— 042 outP. 2 Output 2
— 043 outP. 3 Output 3
— dI Digital inputs (settings via VNC), for Standard
application only
— 044 InP.1on Input 1, condition
— 045 InP.1oF Input 1, condition
— 046 InP.2on Input 2, condition
— 047 InP.2oF Input 2, condition
— 048 InP.3on Input 3, condition
— 049 InP.3oF Input 3, condition
— Ao Analog output, for Standard application only
— 050 AnA.Mod Mode: GroSS; NEtIt = net if tared, otherwise
gross; SELECt; trnSP
— 051 AnA.rnG Range 0/4–20 mA
— 052 out.Err Output on error
— 053 out.< 0 Output if <0
— 054 out.>20 Output if >Max
— 055 WGt.0/4 Weight if 0/4 mA
— 056 WGt. 20 Weight if 20 mA
— oP Operating parameters
— 060 Addr Device address, for Standard application only
