8.5 Filling
Requirements:
- Weighing point is calibrated.
- Production mode is congured; see Chapter 8.4.1.
- Digital inputs and outputs are congured (optional); see Chapter 8.4.2.
- Material (product) is congured; see Chapter 8.4.3.
- Printout is congured (optional); see Chapter 8.4.4.
Example:
- Filling mode: Net lling (B1)
- Interaction mode: VNC
- Digital outputs 1, 2: SPM-Adresse %MX 1162 (coarse)/1163 (ne)
- Material ID: 2
Selection: -none- (no printout; selected if fewer than 6 elements will be printed),
Material name, Gross weight, Net weight, Tare weight, Set point, Date & Time
(printed in format DD.MM.YYYY HH:MM:SS), Sequence number (counter for
individual print orders, max. 6 digits, #000001 comes after #999999), CR/LF
(carriage return and line feed), Form feed
6. Conrm selection.
7. Press the [Print] softkey to print out the conguration if necessary.
8. Press to exit the window.
A prompt window opens.
9. Press the [Yes] softkey to save the changes.
8 Production X3 Process Indicator PR 5410
EN-263 Minebea Intec
