NOTICE
Flow rate measurement problems may occur.
It is imperative to connect the equipotential bonding conductor between PR 1626/
60 and PR 5410.
4.5.9 Connecting an analog weighing platform (CAP… series)
You can connect an analog weighing platform to the device.
NOTICE
The cable colors shown here are valid, for example, for a CAPP4 500 x 400 and a
CAPP1 320 x 420.
The assignments of cable colors are listed in the relevant weighing platform
operating instructions.
Connection designations
Combics 1 to 3 devices PR 5410
BR_POS V+ Supply
SENSE_POS S+ Sense
OUT_POS M+ Meas.
OUT_NEG M- Meas.
SENSE_NEG S- Sense
BR_NEG V- Supply
The cable screens must be connected to the grounding terminal of the device. If the
measuring lines (+M, -M) are screened individually, these screens must be connected to
the grounding terminal as well (see also Chapter 4.3).
X3 Process Indicator PR 5410 4 Device installation
Minebea Intec EN-52
