Minebea Intec X3 Process Indicator PR 5410 User Manual

9.2.5 Screenshots
With the [Screenshot] menu item a screenshot of the device can be displayed, saved and
printed out.
9.2.6 Error log
With the [Show error Log] menu item the error log of the device can be displayed, saved
and printed out.
9. Click on the symbol in the Internet browser to return to the WEB menu.
1. Click on the [Screenshot] menu item in the WEB menu.
The current device display is shown as a screenshot.
2. Press the right mouse button.
3. Click on [Save image as].
4. Create and open the required directory e.g. on the notebook.
5. Click on [Save] to save the graphic le in the relevant directory.
6. Press the right mouse button.
7. Click on [Print].
8. Select the connected printer and click [Print].
9. Click on the symbol in the Internet browser to return to the WEB menu.
1. Click the [Show error Log] menu item in the WEB menu.
The error log of the device is shown on the display.
2. Press the right mouse button.
3. Click on [Save as].
4. Create and open the required directory e.g. on the notebook.
5. Click on [Save] to save the text le in the relevant directory.
6. Press the right mouse button.
9 Extended functions X3 Process Indicator PR 5410
EN-275 Minebea Intec
