Minebea Intec X3 Process Indicator PR 5410 User Manual

Access restriction, Input: authorized client for
instrument operation
— Weighing point A Selection: Internal A, xBPI-scale, Pendeo Load
Cells
— Calib Calibration, selected "Internal A:" New, Modify,
Param, see Chapter 7.13.7.1.
— Setup Setup, "xBPI-Scale" selected: Calibration,
Conguration, Select, Show device info, see
Chapter 7.13.7.2.
— Cong Conguration, "xBPI-Scale" selected: Type,
W&M, Tare timeout, Serial number, SBN
Address, see Chapter 7.13.7.2.
— Param Conguration, "xBPI-Scale" selected: Assigned
to, Baudrate, Bits, Parity, Stopbits, see
Chapter 7.13.7.2
— Assign Assign, "Pendeo Load Cells" selected: Search,
View, Calib, LC name, Service, see
Chapter 7.13.7.3.
— Calib Calibration of the weighing electronics
— New Query window for new calibration: Reset Span
and dead load
Contin, Cancel
— Max Input of the maximum load:
0.00001<3000>999999 <kg>, t, lb, oz, g, mg
— Scale interval Input of the scale interval: <1>, 2, 5, 10, 20, 50
— Dead load at <0.000000 mV/V> or [by load]
[by load]: 0.00001999999 <kg>, t, lb, oz, g,
mg
— Max at <1.000000 mV/V> or [by load]
[by load]: 0.00001999999 <kg>, t, lb, oz, g,
mg
— Calibrated at Display only
— Sensitivity (µV/d) Display only
— Test Determine test value
— Exit calibration Save or discard changes due to new calibration.
— Modify May be used only for minor changes (e.g.
changing the dead load, adapting mV/V values
for dead load and/or Max). Otherwise, always
use [New]!
— Param Parameter settings
— Measuretime Input of the measuring period: 5, 10, 20, 40, 80,
160, <320>, 640, 960, 1280, 1600 ms
— Digital lter Selection of the digital lters: <o>, Bessel,
aperiod., Butterw., Tcheby.
— External supply Selection: below or equal 8 V (≤8 V), <above 8
V> (>8 V)
— Fcut Input of cut o frequency, only unless lter not
"o", 0.1–80.0 Hz
7.13.7 Weighing points
7.13.7.1 "Internal A" weighing point
7 Commissioning X3 Process Indicator PR 5410
EN-151 Minebea Intec
