Minebea Intec X3 Process Indicator PR 5410 User Manual

Singapore [tls], Tael Taiwan [tlt], Grain [GN],
Pennyweight [dwt], Milligram [mg], Parts/
pound [/lb], Tael china [tlc], Momme [mom],
Karat [k], Tola [tol], Baht [bat], Mesghal [m],
Ton [t]
— Display accuracy 13
Chose display accuracy 13: all digits, reduced
when moved, one level lower , two level lower,
three level lower, 1%, 0.5%, 0.2%, 0.1%, 0.05%,
0.02%, 0.01%, Multi-interval, increased by 10
— Interface settings Congure the interfaces
— Communication
type
Communication type: SBI protocol, xBPI
protocol
— Baudrate for
SBI
150 baud, 300 baud, 600 baud, 1200 baud,
2400 baud, 4800 baud, 9600 baud, 19200
baud
— Parity for SBI Select parity: Mark, Space, Odd, Even
— Stop bits Selection: 1 stop bit, 2 stop bits
— Handshake Selection: Software handshake, CTS with 2
chr.pau = CTS with 2 characters , CTS with 1
chr.pau = CTS with 1 character
— Data output
interval
Select Data output interval: with each display,
after 2 updates, after 5 updates, after 10
updates, after 20 updates, after 50 updates,
after 100 updates
— Parameter
change
parameter change: can be changed, cannot be
changed
— Select specication group
— Specif. group 16
Select specication group of the scale (see
operating manual of the relevant scale)
— Show device info
— Set user Enter the user name of the connected device
— Set SBN The xBPI address of the interface has to be <0
>, because there is no bus operation.
— Cong Conguration of the xBPI scale
— Type xBPI-Scale
— W&M Selection legal-for-trade mode: <none>, OIML,
NSC, NTEP
— Tare timeout
Timeout due to instability: 0.1 s<2.0 s>25 s
— Serial number <0>, if >0 the serial number will be checked (at
legal-for trade scale)
— SBN Address <0> no bus operation.
— Param parameter settings of the xBPI scale
— Assigned to Assigned to: xBPI-Port 1
— Baudrate Select transmission speed: <9600>, 19200
— Bits 8
— Parity odd (odd parity)
— Stop bits Selection: <1>, 2
— Assign Assignment of the Pendeo scale
Type, number of load cells, serial number of
each load cell and weighing point serial number
7.13.7.3 "Pendeo® Truck/Process" weighing point
X3 Process Indicator PR 5410 7 Commissioning
Minebea Intec EN-154
