Minebea Intec X3 Process Indicator PR 5410 User Manual

10 ModBus protocol
10.1 General description
The ModBus protocol implemented in the instrument permits fast, simple and reliable
communication between a PC or a PLC and up to 127 instruments.
10.2 SPM data in PR 1612 ModBus mode
For access via ModBus, the PR 1612 ModBus mode is switched on via - [Serial ports]-
[ModBus-RTU]- [Param]- [ModBus mode]- [PR 1612 ModBus].
Read data
Byte address Weight in 32-bit integer format
6063
6467
6871
Gross weight
Net weight (gross if not tared)
Tare weight (0 if not tared)
Read data
Address Read "Word" (display in binary format)
W201 0E00000T 00000000
E: ADC error
T: Instrument is tared.
W203 000S00MZ 00000000
S: Device is in setup mode.
M: Weight is stable (standstill).
Z: Weight within ¼d of 0
W204 0000D000 00000000
D: Gross weight <0 or >Max (dimmed)
W205 TA000000 00000000
T: Instrument is tared.
A: Analog test is active.
W231 00021MRZ 00000000
2: Limit 2
1: Limit 1
M: Weight is stable (standstill).
R: Weight within zero-setting range
Z: Weight within ¼d of 0
Write data
Bit address Value in 32-bit integer format
W100 Zero device:
Write value 256
10 ModBus protocol X3 Process Indicator PR 5410
EN-289 Minebea Intec
