Register 15 Reserved (free)
Register 16 Print gross weight/write to Alibi memory
Register 17 Print net weight/write to Alibi memory
Register 18 Print tare weight/write to Alibi memory
Register 19 Print sequence number/write to Alibi memory
Register 20 Output value (BCD format)
Register 21 Print date/write to Alibi memory (BCD format)
Register 22 Print time/write to Alibi memory (BCD format)
12.2.6.10 Registers 24…29: Limits(Read/Write)
Register 24 Limit 1 on
Register 25 Limit 1 o
Register 26 Limit 2 on
Register 27 Limit 2 o
Register 28 Limit 3 on
Register 29 Limit 3 o
12.2.6.11 Registers 30, 31: Fixed values (Read/Write)
Register 30
Fixed value for analog output; value (num) 020000 corresponds to
20 mA
Register 31 Fixed value for preset tare, see also SetFixTare, GetFixTare in Chap-
ter 12.2.6.3.
12.2.6.12 Registers 80…92: State-controlled action bits (Write)
Note:
For setting bits, see Chapter 12.2.4.3.
Only setting and resetting of single bits is possible.
When changing a bit from 0 to 1, the corresponding action starts. After handling the
command, the bit must be reset. Application: The master writes cyclically.
The bit is set as Write_Value_Select with the specied number (see Chapter 12.2.4.3).
The bit is reset at the specied number +128.
Register 80 SetZero Set the gross weight to zero.
Register 81 SetTare Execute taring.
Register 82 ResetTare Reset tare.
Register 83 SetTest Start the ADC test.
Register 84 ResetTest Finish the ADC test.
X3 Process Indicator PR 5410 12 Fieldbus interface
Minebea Intec EN-304
