Chapter Six: Operation in Tuning Mode How To Ad
j
ust Lead
177
2. Enter the number of the recipe (1 through 4), that needs to have the Lead setting
adjusted.
The system responds by accepting the recipe number.
Note
If the
MANUAL
or
HOLD
legend is displayed,
and
the right display
shows the Edit Reci
p
e
p
arameter (E1, E2, E3, or E4), the left dis
p
la
y
will
blink. The left display is flashing the current control valve position.
Since we want to edit a recipe, you may ignore the blinking left display
and proceed to the next step.
3. Press the [
ON
/
LEAD
] key,
OR
scroll through the Tuning Mode parameters with the
arrow keys until the
LEAD
legend is displayed, then press the [
ENTER
] key.
The system responds by changing the window parameters, and causing the center display
to blink.
4. Enter a value for Lead between 0.001 and 1000 seconds (the default is 1.5 seconds).
A. If the Lead value is already correct, press the [
ENTER
] key.
B. If the Lead value is incorrect, use the [
ZERO
/
EXP
] , [+/-] , and numeral keys to
enter the correct Lead value, then press the [
ENTER
] key.
The system responds by accepting the Lead value.
