Appendix E: Instrument Default Values Default Values
309
Appendix E: Instrument Default Values
Default Values
Active recipe 1
Alarm Relays
Untripped alarm state
Channel assignment (all alarms)
Trip point default
Alarm status
Latch state
Actuated
1
1000 Torr (range ± 105,000 Torr)
Disabled
Off
Alarms - Audio On
Alpha 20
Analog Output End Point
Value
Type
Channel association
1000 Torr
Linear
1
Analog Set Point
Zero voltage
Full scale voltage
Setting
Status
Overrange
Underrange
0.0 Volts
5 Volts
1000 Torr (range 0 to 100,000 Torr)
Disabled
Input > 10.3 Volts
Input < -10.3 Volts
Base 0 (range 0 to 103% of full open)
Baud Rate 9600
