MKS 146C - Table 46: Summary of Setup Mode Codes

General Information Cha
p
ter Seven: O
p
eration in Setu
p
Mode
184
Summary of Setup Mode Codes
Function Left Display Center Display Right Display Main Display
1 Select Volt/
Pressure/ or
Current
Code number - HU (high voltage),
EC (emission
current), or IC (ion
current)
*Main display must
be Volt, or this is
unused
Selects Volt or
PrES (pressure)
2 Select
Pressure Units
Code number - - Selects pressure
unit
3 Edit Audio
Alarms
Code number - - On or Off audio
alarm
4 Adjust Alpha Code number - - Alpha value
5 Set up
RS-232 Port
Code number Data bits and
parity
Data logger or
MKS protocol
Baud rate
7 Set up Main
Display in
Leakage Mode
Code number - - Determine
Leakage Mode
main display
8 Edit Data
Logger Interval
Code number - - Data logger
interval value
10x Adjust
Display Lag
Code number - - Display lag
percent
11x Auto Zero Code number - On/Off Auto Zero Reference channel
number
12x Adjust Ion
Gauge Auto
Power Control
Code number
& channel
number for ion
gauge
Reference
channel number
On/Off auto power
control
Trip point for auto
power control
13x Adjust
Softstart
Code number
and recipe
number
- On/Off softstart
speed function
Softstart speed
14x Set
Polarity &
Control
Channel
Code number
and recipe
number
- Control channel
number recipe
dependent
Select dir (direct)
or rEV (reverse
polarity
Table 46: Summary of Setup Mode Codes
(Continued on next page)
