MKS 146C - Thermocouple Messages

Thermocouple Messages A
pp
endix G: Board S
p
ecific Commands
326
Thermocouple Messages
The 146 instrument supports the MKS TC-1A and the Hastings DV-6M thermocouples.
Thermocouple Messages
Function Description Command Range and Restrictions
Power Channel power @081<para>:<state> <para> is the channel number 1, 2, 3, or 4
<state> is ON for on; OFF for off
Sensor must be installed
Configuration Gas Type @063<para>:<gas> <para> is the channel number 1, 2, 3, or 4
<gas> is N for nitrogen; H for helium;
A for argon
Calibration Zero function @056<para>:<state> <para> is the channel number 1, 2, 3, or 4
<state> is ON for on; OFF for off
Sensor must be installed
Zero channel @051<para> <para> is the channel number 1, 2, 3, or 4
Command only
Sensor must be in range or underrange
Zero function must be on
Auto zero
function
@058<para>:<state> <para> is the channel number 1, 2, 3, or 4
<state> is E for enabled; D for disabled
Auto zero
reference sensor
@059<para>:<ref> <para> is the channel number 1, 2, 3, or 4
<ref> is the ref. channel number
Sensors must be installed
Status Report sensor
status
@608<para>? <para> is the channel number 1, 2, 3, or 4
Request only -
Sensor must be installed
Report sensor
reading
@601<para>? <para> is the channel number 1, 2, 3, or 4
Request only -
Sensor must be installed
Report reading
with time stamp
@602<para>? <para> is the channel number 1, 2, 3, or 4
Request only -
Sensor must be installed
Report sensor
voltage
@603<para>? <para> is the channel number 1, 2, 3, or 4
Request only -
Sensor must be installed
Report channel
condition
@608<para>? <para> is the channel number 1, 2, 3, or 4
Request only -
Sensor must be installed
