Chapter Three: Overview Inside the T
e 146 Unit
47
Inside the Type 146 Unit
General Information
There are six board slots inside the 146 unit. The sixth slot is for the Analog board, which comes
standard with the 146 unit, and must be installed in slot 6. Transducer and MFC boards should
be installed in slots 1, 2, 3, or 4; whichever is the lowest numbered slot available. The 146 unit
can only support one Control board, and one Auxiliary Output board.
Labels are placed on the rear panel to mark the channel number and board type of each board
installed in the unit when it leaves the factory. A complete set of labels is supplied if an
unconfigured base unit is ordered. Additional labels are available (MKS p/n LB-1141011).
Note
Use overall metal braided shielded cables, properly grounded at both
ends, for all connections to ensure CE compliance. Refer to
Interface
Cables
, page 25, for additional information.
