Setup Mode Functions
Miscellaneous Codes Code Functions
Code 1:
Pressure/Volt/Current
Select
Selects pressure, voltage, or current for the main display in Normal
and Leakage Modes.
Code 2:
Pressure Units
Selects Torr, mbar, or Pascal.
Code 3:
Audio Sound
Turns all audio sounds, except the key-press click, On or Off.
Code 4:
Alpha (PID Control)
Edits the alpha value (default value is 20).
Code 5:
RS-232 Port
Configuration
Adjusts RS-232 parameters such as baud rate, protocol, parity, and
data bits.
Code 7:
Leakage Display Setup
Selects either
instantaneous leakage
, or
leakage rate
for the main
display in Leakage Mode.
Code 8:
Data Logger Interval
Edits the data logger interval.
Code 10x:
Adjust Display Lag
Where x is a channel number.
Selects a display sensitivity to accommodate the level of noise in
different gas systems.
Code 11x:
Auto Zeroing
Where x is a channel number.
Auto zeros one channel with a selected reference channel.
Enables/disables the Auto Zero feature.
Code 12x:
Adjust Ion Gauge
Auto Power Control
Where x is a channel number.
Adjusts the auto power shutoff pressure and the reference channel for
the Ion Gauge Auto Power feature, and enables/disables the feature.
Code 13x:
Softstart for Control
(PID Control)
Where x is a recipe number.
Edits the softstart speed.
Table 48: Setup Mode Functions
(Continued on next page)
