MKS 146C - Figure 4: Rear Panel of the 146 Unit

Chapter Two: Installation How To Un
p
ack the 146 Instrument
27
Card Slot 1
Male
Connector
(Pins black)
Female
Connector
(Insulator black)
RS-232
Interface
Line Volta
g
e
Switch
AC
Power
Fuse
General
Interface
(I/O Board)
230V 1.0A
(
T
)
115V 1.6A
(
T
)
Fuses 250V IEC
50/60 Hz
150 VA
Max
Fuses
Line
RS232
COLD CATHODE
BOARD
DUAL PIRANI/
CONVECTION
BOARD
CAPACITANCE
MANOMETER
MASS FLOW
CONTROLLER
BOARD
HOT CATHODE
BOARD
B.C.D
BOARD
AUXILIARY
OUTPUT
BOARD
CONTROL
BOARD
ANALOG
BOARD
Channel 1
Channel 2
C.M.
Interface
High Voltage
Current Input
M.F.C
Interface
Current
Input
H.C.
Interface
B.C.D
.
Interface
Relay
Interface
Analog
Outputs
Valve
Output
Control
Interface
Blank
Cover
Plate
DUAL
THERMOCOUPLE
BOARD
Channel 1
Channel 2
Figure 4: Rear Panel of the 146 Unit
