MKS 146C - Table 45: Summary of Setup Mode Displays

Chapter Seven: Operation in Setup Mode General Information
183
Summary of Setup Mode Displays
Function Left Display Center Display Right Display Main Display
Set Alarm Trip
Points
Alarm letter Channel number
for alarm
On/Off Alarm Alarm trip point
Set Up Dual
Channels
Dual channel
number
and
High/Low
switchpoint
Control channel
number
Continuous (ct) or
discontinuous (dt) or
Off, dual channel
display
Dual channel
switchpoint
Set Up Analog
Outputs
Analog
Output #
Input channel # Output scaling
method
Pressure = Full
scale output or
set point
Sensor
Calibration
Input channel
number
CM: sensor
resolution
Type of gauge CM: sensor range
P: factory or
user-defined
zero/ span
P: gas type
CC: ion gauge
disconnect
threshold value
CC: combined
gauge & GCF
HC: ion gauge
disconnect
threshold value
The letter H or l
above Hc, indicates
high or low powered
hot cathode.
Not
editable here
HC: sensitivity
FC: MFC mode
of operation -
either (SP) or
(to).
Not
editable here
FC: MFC range
Table 45: Summary of Setup Mode Displays
