MKS 146C User Manual

Chapter Nine: RS-232 Communications Command Messa
g
es
283
Read Only Status Messages
Message Description Message Format
@
command
category
command
number
Parameter Data
Optional
checksum
Software Version @ 7 0 1
*
?CR
c1 c2
Channel Status @ 7 0 2
*
?CR
c1 c2
Alarm Status @ 7 0 3
*
?CR
c1 c2
Configuration Setup @ 7 0 4
*
?CR
c1 c2
Rear Panel Status @ 7 0 5
*
?CR
c1 c2
Reference Voltage @ 7 0 6
*
?CR
c1 c2
* Any character may be entered since the parameter field has no significance in the message
Table 82: Read Only Status Messages
Response Format for the Read Only Status Messages
Message Response Description
Software Version <version> CR where <version> represents the software version
number
Channel Status C1:<text>LF CR
C2:<text> LF CR
C3:<text> LF CR
C4:<text> LF CR
where <text> is:
ON = Sensor normal
OFF = Manual off
AOFF = Auto off
DCNT = Disconnected
OVER = Overranged
UNDR = Underranged
INIT = Initializing
ZERO = Zeroing
E1 = Channel error #
- - - - = Channel not
installed
Alarm Status AA:<text>LF CR
AB:<text> LF CR
AC:<text> LF CR
AD:<text> LF CR
where <text> is:
ENAB = Alarm
Enabled
ENAL = In alarmed
state
ENLT = Just latched
DSBL = Alarm disabled
- - - - = Channel not
installed
Table 83: Response Format for the Read Only Status Messages
(Continued on next page)
