MKS 146C - Page 307

Command Messages Cha
p
ter Nine: RS-232 Communications
284
Response Format for the Read Only Status Messages (Continued)
Message Response Description
Configuration (slot status at
power up)
Sx<text> LF CR where x is 1 through 5
<text> is:
CC-- = Cold Cathode
CLN = Linear Cap. Man.
C107 = Type 107 Cap. Man.
C120 = Type 120 Cap. Man.
CNCN = Convection, dual channel
PRCN = Pirani/Convection
C- - - = Cap. Man. board, no sensor
CN - - = Convection, single channel
CNPR = Convection/Pirani
CNTL = Control board
AUXO = Auxiliary Output board
- - - - = Empty slot
PR - - = Pirani, single channel
PRPR = Pirani, dual channel
MFC - Mass Flow Controller
HCL - = Hot Cathode, low power
HCH - = Hot Cathode, high power
1A - - = Thermocouple board
Table 83: Response Format for the Read Only Status Messages
