MKS 146C - Table 72: Control Adjust Messages; Table 73: Chapter References for Control Adjust Messages

Chapter Nine: RS-232 Communications Command Messa
g
es
271
Control Adjust Messages
Message Description Message Format
@
command
category
command
number
Parameter
(Control
channel)
Data
Optional
checksum
Adjust Integral @ 0 3 1 0,* 1 :0.01 to 100 seconds CR
c1 c2
Adjust Base @ 0 3 2 0,* 1 : 0 to 103
(% of full open)
CR
c1 c2
Adjust Start @ 0 3 3 0,* 1 :0 to 103
(% of full open)
CR
c1 c2
Adjust Alpha @ 0 3 4 0,* 1 : 5 to 99, inclusive CR
c1 c2
Adjust Preset @ 0 3 5 0,* 1 :0 to 103
(% of full open)
CR
c1 c2
Adjust Output @ 0 3 6 0,* 1 : 0 to 100% inclusive CR
c1 c2
Ad
j
ust Softstart S
p
eed @ 0 3 7 0,* 1 :1.0 to 990 seconds CR
c1 c2
Analog Set Point F.S. @ 0 3 8 0,* 1 :0 to 10 Volts CR
c1 c2
* Control channel 0 is a virtual control channel used in conjunction with Mass Flow Controllers
Table 72: Control Adjust Messages
Table 73 lists the chapter that explains the function performed by each message.
Chapter References for Control Adjust Messages
Function Chapter
Adjust Integral
Chapter Six: Operation in Tuning Mode
Adjust Base
Chapter Six: Operation in Tuning Mode
Adjust Start
Chapter Six: Operation in Tuning Mode
Adjust Alpha
Chapter Seven: Operation in Setup Mode
Adjust Preset
Chapter Six: Operation in Tuning Mode
Adjust Output
Chapter Seven: Operation in Setup Mode
Adjust Softstart Speed
Chapter Seven: Operation in Setup Mode
Analog Set Point F.S.
Chapter Seven: Operation in Setup Mode
Table 73: Chapter References for Control Adjust Messages
