Electrical Specifications A
endix A: Product S
ecifications
302
Physical Specifications
(Continued)
Digital Output RS-232
Input Power Required 100 to 120 VAC or 220 to 240 VAC, 50/60 Hz
Mounting ½ rack; 9” W x 3½” H x 12” D (24.1 cm x 8.9 cm x 30.5 cm)
Power Supply Output ± 15 VDC @ 2 Amps
Simultaneous Display 1 channel with 4½ place LCD readout (with exponent)
3 channels with 2½ place LCD readouts (with exponents)
Trip Point Relays Standard: 2 alarm relay outputs (28 Volts max.)
Optional: 2 additional alarm relay outputs (120 VAC max.)
Electrical Specifications
CE Mark Compliance
3
Electromagnetic Compatibility
4
Low-Voltage Requirements
Installation Category
Pollution Degree
Product Safety and Liability
EMC Directive 89/336/EEC
Low-Voltage Directive 73/23/EEC
II, according to EN 61010-1
2, according to IEC 664
Product Safety Directive 92/59/EEC
Power Requirement
115 VAC setting
230 VAC setting
100 to 120 VAC, nominal
220 to 240 VAC, nominal
Power Consumption 150 VA, maximum
Fuse Ratings
115 V
230 V
1.6A(T)
1.0A(T)
Due to continuing research and development activities, these product specifications are subject to change without notice.
3
CE compliance depends on the actual configuration of your 146 unit. Some configurations are not CE
compliant.
4
An overall metal braided shielded cable, properly grounded at both ends, is required during use.
