Appendix G: Board Specific Commands Pirani/Convection Messa
g
es
319
Pirani/Convection Messages (Continued)
Function Description Command Range and Restrictions
Calibration Zero function @056<para>:<state> <para> is the channel number 1, 2, 3, or 4
<state> is ON for on; OFF for off
Sensor must be installed
Zero channel @051<para> <para> is the channel number 1, 2, 3, or 4
Command only
Sensor must be in range or underrange
Zero function must be on
Auto zero
function
@058<para>:<state> <para> is the channel number 1, 2, 3, or 4
<state> is E for enabled; D for disabled
Auto zero
reference
sensor
@059<para>:<ref> <para> is the channel number 1, 2, 3, or 4
<ref> is the reference channel number
Sensors must be installed.
Span
function
@057<para>:<state> <para> is the channel number 1, 2, 3, or 4
<state> is ON for on; OFF for off
Span @053<para> <para> is the channel number 1, 2, 3, or 4
Command only
- Span function must be
enabled
Span with
reference
@055<para>:<ref> <para> is the channel number 1, 2, 3, or 4
<ref> is the reference channel number
Span function must be on
Status Report
channel
condition
@608<para>? <para> is the channel number 1, 2, 3, or 4
Request only -
Sensor must be installed
Report
reading with
time stamp
@602<para>? <para> is the channel number 1, 2, 3, or 4
Request only -
Sensor must be installed
Report
channel
reading
@601<para>? <para> is the channel number 1, 2, 3, or 4
Request only -
Sensor must be installed
Report sensor
voltage
@603<para>? <para> is the channel number 1, 2, 3, or 4
Request only -
Sensor must be installed
