16. Gently push the board onto the male connector.
17. Replace the top connector’s fastening screw.
18. Turn the unit over so that it is bottom-side up.
19. Replace the Phillips screw that fastens the board to the 146 unit.
20. Replace the bottom cover by inserting it into the grooves provided, and firmly sliding it
towards the front of the unit. Replace the seven (7) screws that fasten the bottom cover.
The center screw on the bottom cover is slightly off center to avoid interfering with a
connector if a board is positioned in slot 5. Therefore, the cover must be in the correct
orientation for the screw holes to line up properly.
21. Carefully turn the unit right-side up.
22. Replace the top cover by inserting it into the grooves provided, and firmly sliding it
towards the front of the unit. Replace the seven (7) screws that fasten the top cover.
The center screw on the top cover is slightly off center to avoid interfering with a
connector if a board is positioned in slot 5. Therefore, the cover must be in the correct
orientation for the screw holes to line up properly.
23. Replace the four (4) Phillips screws on the outside corners of the rear panel.
24. Plug in the power cord.
