Call Control
3-22 AT Commands Reference Manual December 31, 2007
The following table shows the +CLIP parameters.
Example
AT+CLIP=?
+CLIP: (000,001)//CLI presentation is disabled by the G24 (0) and is enabled by the network (1)
OK
AT+CLIP=1
OK
Example +CLIP indication:
(…incoming call…)
RING
+CLIP: "2173845400",129,,128,"Doe John",0
Example +CLIP indication with restricted CLI:
AT+CRC=1
OK
(…incoming call…, caller restricted the CLI presentation (used AT+CLIR)…)
+CRING: VOICE
+CLIP: "",128,,128,"",1
Table 3-8: +CLIP Parameters
<Parameter> Description
<n> Enables/disables the CLI presentation indication after the ring indication:
0 Disable CLI presentation
1 Enable CLI presentation
The default is 0.
<m> Shows the subscriber CLIP service status in the network:
0 CLIP not provisioned
1 CLIP provisioned
2 Unknown (for example, no network and so on)
<"number"> Calling line number. The number format is specified by <type>.
<type> Type of address octet in integer format:
145 Default when the dialing string includes the international access code character
"+".
129 Default when making a local call.
128 Type of number is unknown (usually the output when the number itself is
unknown).
<subaddr> NULL, field not used (String type subaddress of format specified by <satype>)
<satype> Field not used. Value is always 128 (unknown) - type of sub address octet in integer
format.
<"alpha"> Name of the calling party (if provided by the network or if the number is found in the
G24 phone books).
<CLI validity> The Validity of the Calling Line Identity presentation:
0 CLI valid.
1 CLI has been withheld by the originator.
2 CLI is not available due to networking problems or limitations of the
originating network.
