Chapter 3: AT Commands Reference
December 31, 2007 AT Commands Reference Manual 3-399
Example
AT+MIPFLUSH=2//Socket number 2 was previously opened using the +MIPOPEN command
+MIPFLUSH: 2
OK
AT+MIPFLUSH=5
ERROR
AT+MIPFLUSH?
+MIPFLUSH: 1 2
OK
+MIPRUDP, Receive Data from UDP Protocol Stack
This unsolicited event is sent by the G24 to the terminal when data is received from the UDP
protocol stack.
Set Command Event
+MIPRUDP:<Source IP>,<Source Port><socket ID>,<Left>,<Data>
The following table shows the +MIPRUDP parameters.
Example
+MIPRUDP: 172.16.3.135,222,2,0,44444444
+MIPRTCP, Receive Data from TCP Protocol Stack
This unsolicited event is sent by the G24 to the terminal when data is received from the TCP
protocol stack.
Note: In case of SSL secured connection, the encryption increases the amount of data and SSL
protocol uses encrypted alerts, therefore the <Left> parameter shows gross encrypted
amount of data (including encrypted alert messages) still left in protocol stack, which is
greater than actual amount of decrypted data.
Set Command Event
+MIPRTCP: <socket ID>,<Left>,<Data>
Table 3-268: +MIPRUDP Parameters
<Parameter> Description
Source IP IP of the source
Source Port Port of the source
Socket ID 1,2,3,4 - Number of valid sockets.
Left Size of received Data still left in protocol stack.
Data Data string received with 0-F hexadecimal digits. String ends with a <CR>.
