Chapter 3: AT Commands Reference
December 31, 2007 AT Commands Reference Manual 3-7
The following table shows the information items that are supported by the G24.
Example
ATI7
G24 OEM Module
OK
ATI8
G24_G_0C.11.61R
OK
ATI9
GCEG24x000AA028
OK
+CNUM, Request MSISDN(s)
This command displays up to five strings of text information that identify the G24. The output
string contains double quotes.
On SIM cards that have EFmsisdn file, the string(s) returned are the MSISDN numbers and their
associated data.
On SIM cards that don't have EFmsisdn file, the strings returned are the MSISDN numbers and
their associated data stored in G24 NVM.
ATIn Description Output
3 Reports Product Title Motorola Mobile Phone
5 Reports Software Architecture P2K
7 Reports Product Description <current module type>
8 Reports Software Version <current software revision>
9 Reports Flex Version <current flex version>
